3.5 inch Suspension Lift Kit - Level 2

THIS PRODUCT IS CURRENTLY ON BACKORDER

• Drop Pitman Arm - ETA N/A

TOMS OFFROAD Level 2 Suspension Lift Kit for 66-77 Ford Broncos. This lift kit will lift the suspension by approximately 3.5 inch from the stock position.

This early Bronco lift kit includes the following parts:

• 3.5 inch Progressive Rate Long Travel Coil Springs
• 14-piece 7 Degree C-Bushing Kit (C-Bushings, Radius Arm Rear Bushings & Track Bar Bushings w/Sleeves)
• Tracking Bar Drop Bracket
• 3.5 inch Lift 11-pack Rear Progressive Rate Leaf Springs
• 6 degree Leaf Spring Shims
• 4 inch Drop Pitman Arm
• Extended Driver & Passenger E-Brake Cables
• Extended Front Center Brake Hose
• Extended Rear Center Brake Hose
• Leaf Spring & Shackle Bushings
• Heavy Duty U-Bolts
• 4 x TOMS OFFROAD Shock Absorbers.

Deluxe Kit also includes:

• Upgraded 5/8 inch U-Bolts w/HD U-Bolt Retainer Plates
• Leaf Spring & Shackle Mounting Hardware
• 2 x OE Style Shackles
• Adjustable Draglink (Only for 66-75 applications)
• Adjustable Tracking Bar

NOTE: When lifting your Bronco 3.5 inch or more, you will need to extend your front & rear drivelines if you have the stock 3-spd or C4 Auto Transmission. For your convenience we have added the option of adding these extended drivelines to your kit when you add this item to your cart.

CLICK HERE FOR INSTALLATION INSTRUCTIONS

The Bronco shown for reference has a 3.5 inch lift with 35 x 12.50 Tires
