5.0L Coyote Engine Conversion

A complete 5.0L Coyote swap kit for the Ford Bronco typically includes engine mounting plates or towers, motor mount isolators, and header options designed for the Bronco's chassis dimensions. Tom's Offroad carries Coyote conversion kits developed specifically for the 1966–1977 early Bronco to simplify fitment and reduce custom fabrication.

The Gen 3 5.0L Coyote produces 450–480 horsepower in stock form from a modern Mustang GT donor, a significant upgrade over the original early Bronco 302's roughly 200 hp. In a lighter early Bronco body, the power-to-weight ratio makes this swap extremely potent. Additional tuning and supporting modifications can push output higher.

Common transmission choices for a Coyote-swapped early Bronco include the Tremec T56 or TR3650 manual transmissions and the 6R80 or 10R80 automatic. Adapter plates or custom crossmembers are required to mate the transmission to the Bronco's chassis. The 6R80 or 10R80 transmissions must come from a F150 4x4 application for proper fitment.

The 5.0L Coyote is a fuel-injected engine by design and requires an EFI system to operate. Most Coyote swap builds retain the factory Ford engine management system using a standalone harness kit, which simplifies tuning and allows use of a Mustang GT tune as a starting baseline. Carbureted Coyote setups do not exist in any meaningful production form.

The Coyote is not a direct drop-in, it's physically larger than the original 302 and requires a dedicated engine mount kit, modified or custom headers, and firewall clearance modifications in some cases. Quality bolt-in swap kits from specialists like Tom's Offroad eliminate a lot of custom fabrication, making the swap accessible to experienced home builders.
